BL/IV Series High-efficiency Clinker Cooling Machine

The air cooling system and trolley pushing system of the high-efficiency clinker cooling machine are independently separated, eliminating the friction failure caused by the mutual movement of the traditional cooling machine's movable grate bed, and ensuring the continuous, stable, and efficient operation of the clinker burning system.

A cold material layer is installed between the trolley shaped conveying device and the heat-resistant stainless steel grate bed to prevent the grate plate from being exposed to thermal radiation and wear. Ensure long-term use of the grate plate.

An independent automatic flow regulating cooling system ensures a reasonable distribution of cooling, effectively reducing the power of the fan distribution by 15% to 20%.

The conveying device in the form of a cart provides effective protection for the grate bed, without material leakage, thermal expansion, or a material pulling machine.

Standardized wear-resistant components for quick replacement during on-site maintenance.

Standardized module design can be arranged to form a cooling machine for a 1500-6000t/d cement clinker production line according to user requirements.

The conveying device in the form of a small car is driven by hydraulic control, achieving the integration of machinery, electricity, and fluid, simplifying the control system, and ensuring smooth and reliable clinker conveying.

Compared with traditional cooling machines, it has a smaller size and saves civil construction investment and electricity consumption.

The hydraulic control components are imported from Germany, ensuring safety and reliability.

The entire equipment has fewer worn parts, low maintenance costs, and low operating costs.
